| Name | Data | |
|---|---|---|
| BASIC | Operating Weight | 3000 kg |
| Weight Burden on Front Drum | 1500 kg | |
| Weight Burden on Rear Wheel | 1500 kg | |
| Min Ground Clearance(h) | 252 | |
| Wheelbase (L1) | 2000 | |
| Grade Ability | 30% | |
| L×W1×H (mm) | 2750×1350×2760 | |
| ENGINE | Manufacturer | QUAN CHAI |
| Model | 3B2-38C31 | |
| Displacement | 1.91L | |
| Fuel consumption | 7.7L | |
| Rated Power | 28 kW | |
| Rated Speed | 2600 rpm | |
| Emissions Standard | Nation Ⅲ | |
| DRIVE TRAIN | Drive Type | Hydrostatic Drive |
| Travel Speed Forward | 0-8 km/h | |
| Travel Speed Reverse | 0-8 km/h | |
| Tire Type | — | |
| Min.Turning Radius | 4000 mm | |
| Steering Angle | 33 ° | |
| Swing Angle | ±10 ° | |
| VIBRATION SYSTEM | Width of Drum (W2) | 1200 mm |
| Diameter of Drum | 710 mm | |
| Rim Thickness of Drum | 12 mm | |
| Static Linear Load | 125/125 N/cm | |
| Vibration Type | Open-loop Hydraulic Vibration | |
| Centrifugal Force | 30 kN | |
| Vibration Frequency | 50 Hz | |
| Nominal Amplitude | 0.5 mm | |
| BRAKE SYSTEM | Service Brake | Hydraulic Lock Front and Rear Brake |
| Parking Brake | Oil Cut Front and Rear Wheel Brake | |
| ELECTRIC | Voltage | 12 V |
| Capacity | 120×2 Ah | |
| SERVICE REFILL | Fuel Tank Capacity | 50 L |
| Hydraulic Tank Capacity | 75 L |
